ND3341 Series

Regular price
$300.00
Sale price
$300.00
Regular price
$380.00
Sold out
Unit price
per

The ND3341 Series features:

  • Complies with NEMATS1 & TS2 Environmental requirements for Traffic control equipment
  • Specific design for industrial communication application with UL508 safety certification
  • Complies with IEC61000 –6 –2 EMC Generic standard immunity for Industrial environment
  • Ethernet Port: 10/100Mbps –Full –duplex, Auto –Negotiation, Auto –MDI/MDIX
  • Ethernet Extender Port: Symmetrical on the VDSL, High –speed full –duplex up to 85 Mbps communications link over existing coaxial cable
  • IEEE802.3x Flow control for full duplex
  • Ten speeds with speed indicator LEDs on front panel of unit Up to 85Mbps@about 200meters (656ft.) 1Mbps@about 2,600meters (8,530ft.)
  • –40°C to 75°C ( –40°F to 167°F) operating temperature range
  • Redundant power inputs with Terminal Block and DC Jack
  • DIP switch to select Local or Remote side
  • Hardened aluminum case
  • Compatible with ED3331, ED3344 and ED3371
  • Supports DIN –Rail Panel Rack Mounting installation
